The TCRT5000 Module is an infrared reflective optical sensor, commonly used for object detection, line-following robots, and various other applications that require proximity or distance sensing. It consists of an infrared emitter (LED) and a phototransistor detector, which work together to detect the reflection of the emitted infrared light off of nearby objects.

Category:

Description

TCRT5000 Infrared Reflective Sensor Module

The TCRT5000 Module is an infrared reflective optical sensor, commonly used for object detection, line-following robots, and various other applications that require proximity or distance sensing. It consists of an infrared emitter (LED) and a phototransistor detector, which work together to detect the reflection of the emitted infrared light off of nearby objects.


Key Features:

  • Infrared Emitter and Phototransistor: The TCRT5000 uses an IR LED and a phototransistor to detect reflected infrared light from an object.
  • Object Detection: Ideal for detecting the presence or absence of an object or surface, useful in robotics, automation, and proximity sensing.
  • Reflective Sensing: The sensor works by emitting infrared light towards a surface and measuring the amount of reflected light, which varies depending on the distance and color of the object.
  • Compact and Easy to Use: The module is compact, simple to integrate with microcontrollers like Arduino, Raspberry Pi, or other development boards for easy project implementation.
  • Adjustable Sensitivity: Some versions of the module come with an adjustable potentiometer to fine-tune the sensitivity for different applications.
  • Wide Range of Applications: Used in line-following robots, obstacle detection, edge sensing, position tracking, and more.

Specifications:

  • Operating Voltage: 3.3V to 5V
  • Current Consumption: ~20mA (typical)
  • Detection Range: Typically 1 to 3 cm, depending on the reflective surface and ambient conditions.
  • Response Time: < 10 µs
  • Output Type: Digital (High or Low output)
  • Mounting Type: 2-pin or 3-pin connector for easy integration into breadboards or circuits.
  • Output Logic: High when no reflection is detected, Low when a reflection is detected.

Applications:

  • Line Following Robots: Commonly used in DIY robotics to detect the line on the ground for autonomous navigation.
  • Object Detection: Used in robotics or automation systems to detect objects or obstacles.
  • Position Sensing: Detects positions or boundaries for automated systems, such as in conveyor belts or sorting systems.
  • Edge Detection: Helps robots or automated systems recognize when they are near the edge of a surface or platform.
  • Proximity Sensing: Can be used in a variety of proximity sensing applications, where object detection is essential.
  • Speed or RPM Measurement: Can be used for detecting the rotation of a wheel or disk to calculate speed in mechanical systems.

The TCRT5000 Module is a versatile and affordable infrared sensor, perfect for a wide range of applications that require reliable, short-range object detection or proximity sensing. Whether you’re working on robotics, automation, or educational projects, the TCRT5000 offers a great solution for infrared sensing.
