CD4047BE

Overview

Product Overview The CD4047BE is a versatile integrated circuit capable of operating as both an astable and monostable multivibrator. This IC is widely used in various timing and oscillator applications, making it a valuable component for engineers and hobbyists alike. Specifications

• Type: Astable/Monostable Multivibrator
• Package Type: DIP-14 (Dual In-line Package)
• Operating Voltage: 3V to 15V
• Frequency Range: 0.01Hz to 100kHz (Astable Mode)
• Output Voltage Swing: Close to VDD
• Temperature Range: 0°C to +70°C

Key Features

• Dual Functionality: Configurable as either an astable or monostable multivibrator, providing flexibility for various applications.
• Adjustable Frequency: The output frequency can be easily adjusted using external resistors and capacitors.
• High Noise Immunity: Designed to perform well in noisy environments, making it suitable for industrial applications.
• Low Power Consumption: Efficient operation ensures minimal power usage, ideal for battery-powered devices.
• Easy to Use: Simple pin configuration allows for straightforward integration into circuits.

Applications

• Timing Circuits: Used in timer applications for generating precise time delays.
• Clock Generation: Can function as a clock generator for digital circuits.
• Oscillator Circuits: Suitable for generating square wave signals for various applications.
• Frequency Modulation: Employed in systems requiring frequency modulation and signal processing.

Package Includes

• 1 x CD4047BE Astable/Monostable Multivibrator IC

Additional Notes Refer to the datasheet for detailed specifications, application circuits, and configuration examples.
