The LilyGo T-Display CH9102F 16M is a versatile and compact development board featuring an integrated 1.14-inch IPS color display. Powered by the CH9102F chip and equipped with 16MB flash memory, this board offers both easy display control and ample memory for a wide range of embedded applications. With the added benefit of Wi-Fi and Bluetooth support through the ESP32 microcontroller, the LilyGo T-Display is perfect for projects that require a display interface and wireless communication.

Category:

Description

LilyGo T-Display CH9102F 16M

The LilyGo T-Display CH9102F 16M is a versatile and compact development board featuring an integrated 1.14-inch IPS color display. Powered by the CH9102F chip and equipped with 16MB flash memory, this board offers both easy display control and ample memory for a wide range of embedded applications. With the added benefit of Wi-Fi and Bluetooth support through the ESP32 microcontroller, the LilyGo T-Display is perfect for projects that require a display interface and wireless communication.


Key Features:

1.14-inch IPS Display: A small but sharp 1.14-inch IPS LCD screen with a 240×135 resolution for displaying text, graphics, and simple UI elements. Its wide viewing angle and high brightness make it ideal for embedded projects where screen space is limited.
ESP32 Chip: Powered by the ESP32 microcontroller, it offers dual-core processing and supports Wi-Fi and Bluetooth connectivity, perfect for IoT and wireless communication applications.
CH9102F USB to Serial Chip: This USB-to-serial chip simplifies communication between the development board and your computer, making it easy to upload sketches or monitor serial output.
16MB Flash Memory: Comes with 16MB flash memory, providing ample storage for code, data, and additional libraries.
Compact and Portable: The compact size of the board (with the display included) makes it easy to incorporate into small projects and designs.
Easy to Use: Designed with Arduino compatibility in mind, this board is easily programmable using the Arduino IDE, making it perfect for both beginners and advanced users.
Low Power Consumption: The ESP32 chip provides excellent power management options, making the board suitable for battery-powered applications.


Specifications:

  • Microcontroller: ESP32 (dual-core processor, up to 240 MHz)
  • Display: 1.14-inch IPS LCD with a resolution of 240×135
  • Flash Memory: 16MB
  • Connectivity: Wi-Fi, Bluetooth
  • USB to Serial Chip: CH9102F
  • Operating Voltage: 3.3V
  • Input Voltage: 5V via micro USB
  • Pinout: Provides access to various GPIO pins, I2C, SPI, PWM, and ADC for flexible integration with external sensors or modules.
  • Dimensions: Approx. 50mm x 30mm
  • Power Supply: Powered via micro USB or 3.3V supply for lower-power applications
  • Programming: Compatible with Arduino IDE or PlatformIO

Applications:

Portable Projects: The compact size and low power consumption make this board suitable for portable and battery-operated devices like wearables or handheld gadgets.
IoT Devices: Utilize the Wi-Fi and Bluetooth functionality for building IoT devices that need both display and wireless communication.
Wireless Sensors & Monitors: Great for creating sensor networks where data is displayed locally on the small screen and sent wirelessly to a server or other devices.
Home Automation: Integrate the board with home automation systems to display data from connected devices such as temperature, humidity, or motion sensors.
Data Visualization: Use it as a data display unit for visualizing sensor readings, environmental data, or control system outputs in small projects or prototypes.
Educational Projects: Perfect for learning about microcontrollers, displays, and wireless technologies in educational or prototyping environments.


What’s Included:

  • LilyGo T-Display CH9102F 16MB development board
  • Micro USB Cable for power and programming
  • Documentation for getting started with coding and connecting peripherals

Note: Ensure to check the board’s compatibility with your development environment (Arduino IDE or PlatformIO) for easy setup and integration. This board is perfect for small screen-based projects where space is tight and wireless communication is necessary.
