xhp-3 Connector

3.00

Product Overview
The XHP-3 Connector is a 3-pin JST (Japan Solderless Terminal) connector, widely used in electronics for secure and reliable wire-to-board connections. Known for its compact size and robust design, the XHP-3 is commonly found in hobby electronics, battery connections, LED connections, and sensor interfaces.

SKU: NE0000089 Category:

Description

Product Overview
The XHP-3 Connector is a 3-pin JST (Japan Solderless Terminal) connector, widely used in electronics for secure and reliable wire-to-board connections. Known for its compact size and robust design, the XHP-3 is commonly found in hobby electronics, battery connections, LED connections, and sensor interfaces.

Specifications

  • Connector Type: JST XH Series, XHP-3 (3-pin)
  • Pin Count: 3
  • Pitch: 2.5mm
  • Current Rating: 3A
  • Voltage Rating: 250V AC/DC
  • Material: Nylon 66 (UL 94V-0 rated for flammability)
  • Contact Resistance: ≤ 20mΩ
  • Operating Temperature: -25°C to +85°C
  • Dimensions: Compact design suitable for tight spaces

Key Features

  • High Reliability: Secure connection with tight contact resistance
  • Compact Design: Saves space on PCBs, ideal for smaller electronic builds
  • Easy Installation: Push-in design ensures straightforward assembly
  • Durable Construction: High-quality materials for long-lasting performance
  • Versatile Application: Perfect for connectors in RC vehicles, LED lighting, DIY electronics, and embedded systems

Applications

  • Battery Connections: Commonly used in Li-ion battery packs and RC applications
  • LED Connections: Great for connecting LED strips or modules
  • Sensor Interfaces: Suitable for small sensor projects and devices
  • Prototyping and Hobby Projects: Ideal for quick, solder-free connections in various electronics projects

Package Includes

  • 1 x XHP-3 Connector (3-pin)

Additional Notes
Compatible with 22-28 AWG wire and pairs well with crimp terminals for secure connections. Ensure proper crimping tools and techniques for optimal results.
