Description
SMD Resistor 47KΩ 1/16W 5% 0402 – Surface Mount Resistor
Overview:
This is a 47KΩ (47,000 ohms) Surface Mount (SMD) Resistor with a 0402 package size, 1/16W (0.0625W) power rating, and 5% tolerance. It is commonly used in compact electronic circuits for current limiting, signal conditioning, and voltage division.
Key Features:
✔ Resistance: 47KΩ (47,000 ohms)
✔ Power Rating: 1/16W (0.0625W)
✔ Tolerance: ±5%
✔ Package Size: 0402 (1.0mm × 0.5mm)
✔ Temperature Coefficient: ±200 ppm/°C (typical)
✔ Mounting Type: Surface Mount (SMD)
✔ RoHS Compliant & Halogen-Free
Technical Specifications:
| Parameter | Value |
|---|---|
| Resistance Value | 47KΩ (47,000 ohms) |
| Tolerance | ±5% |
| Power Rating | 1/16W (0.0625W) |
| Package Size | 0402 (1.0mm × 0.5mm) |
| Temperature Coefficient | ±200 ppm/°C (typical) |
| Operating Temperature Range | -55°C to +155°C |
| Mounting Type | SMD (Surface Mount) |
| Material | Thick Film |
Applications:
✅ Voltage Divider Circuits – Signal conditioning
✅ Current Limiting Resistor – Used in microcontroller circuits
✅ Consumer Electronics – Compact circuit designs
✅ Embedded Systems – Low-power applications
✅ General-Purpose Electronics – Power and signal applications
Recommended Alternatives:
🔹 Yageo RC0402JR-0747KL – 47KΩ, 5%, 1/16W, 0402 resistor
🔹 Vishay CRCW040247K0JNED – High-quality alternative
🔹 Samsung RC1005J473CS – Cost-effective option
Package Includes:
✔ 1 x SMD 47KΩ Resistor (1/16W, 5%, 0402)
